Teaching young physicsts the fundamentals of object oriented programming is a fun and satisfying part of my PhD. As a Graduate Teaching Assistant, I am on hand in practical computer laboratory sessions to help students who are struggling with their assignments or just curious about coding in general. I'm now in my third year in this role and I really enjoy having the opportunity to refine my knowledge and computational problem solving skills each week.

The course

This course is designed to teach physics students, who may have only taken one course in programming before, all of the main concepts of Object Oriented Programming:

• Classes and objects
• Encapsulation - controlling how data can be used
• Inheritance - creating class hierarchies
• Polymorphism - one interface, multiple methods
• Templated code
• Best practices - organisation, headers, namespaces, comments, etc.

Example - geometry & inheritance

This is an example of my work and the kind of code that we are helping people to write. Here we demonstrate the value of class hierarchies and polymorphism while designing a code to calculate the properties of various shapes.

/* shape.cpp
 *  - Example code for the 3rd year undergraduate OOP programming course I teach on
 *  - This assignment asks students to use class hierarchy and polymorphism to
 *    build a code that finds the area and volume of different shapes.
 *  - In this code I use abstract base classes for shapes of different numbers
 *    of dimensions, then derive classes for individual shapes.
 *  - The prism class uses a base class pointer to access the area function
 *    of any 2D shape class, from which arbitrary prisms may be constructed.
 *
 * Max Potter 2018
 */

#define _USE_MATH_DEFINES // for M_PI

#include<iostream>
#include<string>
#include<vector>
#include<cmath>

using namespace std;

const int err_novolume(10); // Throw error when calculating volume of flat shape

// Abstract base class - all shapes derive from here
class shape {
  public:
    // All shapes have functions to calculate area, volume and return a string containing their name
    virtual double area() = 0;
    virtual double volume() = 0;
    virtual string tag() = 0;

    virtual ~shape(){}
};

// Abstract derived class for all 2D shapes
class shape2d : public shape {
  public:
    // 2D shapes are flat and have zero volume
    double volume() {throw err_novolume;}

    virtual ~shape2d(){}
};

class rectangle : public shape2d {
  private:
    // private member variables for each dimension of the rectangle
    double x, y;

  public:
    rectangle(): x(0), y(0) {}
    rectangle(double xin, double yin): x(xin), y(yin) {}

    double area(){return x * y;}
    virtual string tag(){return "rectangle";} // virtual: overridden in derived square class

    ~rectangle(){cout << "Destroying rectangle object" << endl;}
};

// Squares are just a special case of rectangles so can inherit from rectangle
class square : public rectangle {
  public:
    square():rectangle(){}
    square(double xin):rectangle(xin, xin){}

    string tag(){return "square";}

    ~square(){cout << "Destroying square object" << endl;}
};


class ellipse : public shape2d {
  protected:
    double rx, ry;

  public:
    ellipse():rx(0), ry(0){}
    ellipse(double rxin, double ryin):rx(rxin), ry(ryin){}

    double area(){ return M_PI * rx * ry;}
    virtual string tag(){return "ellipse";} // virtual: overridden in derived circle class

    ~ellipse(){cout << "Destroying ellipse" << endl;}
};

// Similarly to squares, circles are just ellipses with extra symmetry
class circle : public ellipse {
  public:
    circle():ellipse(){}
    circle(double rin):ellipse(rin, rin){}

    string tag(){return "circle";}

    ~circle(){cout << "Destroying circle" << endl;}
};

// Abstract derived class for all 3D shapes
class shape3d : public shape2d {
  public:
    virtual ~shape3d(){}
};

class cuboid : public shape3d {
  private:
    double x, y, z;

  public:
    cuboid():x(0), y(0), z(0){};
    cuboid(double xin, double yin, double zin):x(xin), y(yin), z(zin){};

    double volume(){return x * y * z;}
    double area(){return 2 * (x * y + x * z + y * z);}
    virtual string tag(){return "cuboid";} // virtual: overridden in derived cube class

    ~cuboid(){cout << "Destroying cuboid" << endl;}
};

// Cubes are cuboids in the most simple case
class cube : public cuboid {
  public:
    cube():cuboid(){}
    cube(double xin): cuboid(xin, xin, xin) {}

    string tag(){return "cube";}

    ~cube(){cout << "Destroying cube" << endl;}
};

class ellipsoid : public shape3d {
  private:
    double rx, ry, rz;

  public:
    ellipsoid(): rx(0), ry(0), rz(0){}
    ellipsoid(double rxin, double ryin, double rzin): rx(rxin), ry(ryin), rz(rzin){}

    double volume(){return 4./3. * M_PI * rx * ry * rz;}
    double area(){
      // Approximation: Knud Thomsen formula (error < 1% for p = 1.6075)
      const double p = 1.6075;
      return 4 * M_PI * pow((pow(rx * ry, p) + pow(rx * ry, p) + pow(rx * ry, p)) / 3., 1./p);
    }
    virtual string tag(){return "ellipsoid";} // virtual: overridden in derived class sphere

    ~ellipsoid(){cout << "Destroying ellipsoid" << endl;}
};

// Spheres are ellipsoids in the most simple case
class sphere : public ellipsoid {
  public:
    sphere() : ellipsoid() {}
    sphere(double r) : ellipsoid(r, r, r) {}

    string tag(){return "sphere";}

    ~sphere(){cout << "Destroying sphere" << endl;}
};

// A prism is any 2D shape extruded along the out-of-plane axis
class prism : public shape2d {
  private:
    double z; // height/depth of prism
    shape2d *ptr_shape2d; // base class pointer to any 2D shape, which when extruded forms a prism

  public:
    prism(double zin, shape2d *shape2din):z(zin), ptr_shape2d(shape2din){};

    double area(){return ptr_shape2d->area();}
    double volume(){return ptr_shape2d->area() * z;}
    string tag(){return ptr_shape2d->tag() + " prism";}

    ~prism(){cout << "Destroying prism" << endl;}
};

int main(void) {
  vector<shape*> myshapes; // vector of base class pointers to store instances of derived shapes
  vector<shape*>::iterator myshapeit;

  // Add shapes
  myshapes.push_back(new square(4));
  cout << "Area of " << myshapes[0]->tag() << " = " << myshapes[0]->area() << endl;

  myshapes.push_back(new rectangle(4, 5));
  cout << "Area of " << myshapes[1]->tag() << " = " << myshapes[1]->area() << endl;

  myshapes.push_back(new circle(3));
  cout << "Area of " << myshapes[2]->tag() << " = " << myshapes[2]->area() << endl;

  myshapes.push_back(new cube(4));
  cout << "Area of " << myshapes[3]->tag() << " = " << myshapes[3]->area() << endl;
  cout << "Volume of " << myshapes[3]->tag() << " = " << myshapes[3]->volume() << endl;

  myshapes.push_back(new cuboid(4, 5, 6));
  cout << "Area of " << myshapes[4]->tag() << " = " << myshapes[4]->area() << endl;
  cout << "Volume of " << myshapes[4]->tag() << " = " << myshapes[4]->volume() << endl;

  myshapes.push_back(new sphere(3));
  cout << "Area of " << myshapes[5]->tag() << " = " << myshapes[5]->area() << endl;
  cout << "Volume of " << myshapes[5]->tag() << " = " << myshapes[5]->volume() << endl;

  myshapes.push_back(new prism(10, (shape2d*)myshapes[0]));
  cout << "Area of " << myshapes[6]->tag() << " = " << myshapes[6]->area() << endl;
  cout << "Volume of " << myshapes[6]->tag() << " = " << myshapes[6]->volume() << endl;


  myshapes.push_back(new prism(15, (shape2d*)myshapes[2]));
  cout << "Area of " << myshapes[7]->tag() << " = " << myshapes[7]->area() << endl;
  cout << "Volume of " << myshapes[7]->tag() << " = " << myshapes[7]->volume() << endl;

  // Clean up
  for(myshapeit = myshapes.begin(); myshapeit < myshapes.end(); ++myshapeit)
    delete *myshapeit;
  myshapes.clear();

  return 0;
};
